Product Overview
MX135 Venus Avatar
Glass-Metal-Ceramic Hybrid X-Ray Tube having high dissipation, high throughput, graphite-backed metal target tube for Brivo 315/325/385, Revolution™ ACT, Revolution™ ACTs, Optima 640 and NM850/860 systems.
Glass Metal Ceramic Hybrid Frame
Unique combination of Glass-Metal and Ceramic to form vacuum envelope to provide stability and long-life with higher HV stability over the lifetime of the tube.
Higher Throughput
• Brazed graphite target design utilizing a patented braze process provides integrity of the graphite to metal bond at temperatures more than 1300°C at the target rim.
• Unique insert and housing design facilitate high-heat radiation technology which quickly transfers generated heat at the anode to the ambient environment.
• High-heat transfer technology in conjunction with a 2.0 MHU,135 mm diameter target provides excellent throughput.
Consistent Imaging
• Metal center frame with legacy target design to achieve improved high-voltage stability for consistent techniques.
• Insert processing designed for better high voltage stability and vacuum integrity over life
Longer Tube Life
• Glass-Metal-Ceramic Hybrid insert design for best of High Voltage stability
• Innovative preloaded bearing design with heat block mechanisms and three-ball floating rear retainer permits trouble-free rotor operation.
• High-voltage surge protection designed into the tube unit provides exceptional high voltage stability. Additionally, each insert is conditioned to a minimum of
185 kV which provides stability up to the 140 kV tube rating.
• Three-piece casing design with improved sealing joints, hoses and stator feedthrough for better reliability and integrity of the internal housing environment.
