Main Power Supply Compatible with CW Option
5205052-3
5205052-4
Ultrasound
LOGIQ E9
GE Healthcare
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.


Product Overview

The Main Power Supply is specially designed DC regulated voltage intended for use in GE ultrasound system. The Main Power Supply’s main task is to galvanically isolate the scanner from the on-site Mains Power System and to supply the various internal subsystems with AC or DC power. It is an AC/DC converter generating all main DC voltages at or above 6V. The power supply includes all AC components such as the mains input connector, fuses, filters, and inrush current limiter. The main power supply also has an inverter for 110V output (isolated side). This power supply operates at 100 to 240 VAC input voltage and offers DC output required by the system. It delivers the needed voltages to the rest of the LOGIQ™ E9 which are internal printer (110 VAC), front end rack (DC power with several voltages), front end rack (TSV1 and TSV2 for the transmitters), front end rack (PMXVOUT for the probe channel multiplexers) and back end processor (BEP). This RoHS compliant power supply is compatible with CW option and can be used with GE's Logiq E9 Ultrasound Systems.

Compatible Products

LOGIQ E9

LOGIQ E9

The LOGIQ* E9 is a versatile general imaging system that helps meet a wide variety of general imaging needs. As healthcare evolves and ultrasound exams become more in demand, you need the ability to adapt to the changing environment with an ultrasound system that gives you flexibility, ease of use, speed and reliability.

The LOGIQ E9 can help you:

Deliver extraordinary image quality on a broad spectrum of patient body types.
Visualize blood flow without the limitations of Doppler
Enhance your workflow.
Integrate real-time ultrasound with previously acquired CT, MR, PET, or ultrasound images.
Visually track your position during a scan.

Equivalent Part :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
5205052-4

The Main Power Supply Universal AC Input, 100V-240V Ichir
