High Voltage (HV) Cable 5128609-10
5128609-10
5128609-4
Computed Tomography (CT)
Optima 520
GE Healthcare
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Product Overview

This high voltage cable is used in the CT systems for establishing connection with the high voltage generator to transmit high voltage to anode and cathode of the x-ray tube and transfer the heating voltage to the x-ray tube filament. The high voltage cable assembly comprises of two cylindrical spring loaded plug connectors having three contact pins of length 8.1 mm and Diameter 4 mm. These connectors are connected using a specialized high voltage cable having 3 tinned copper conductors of size 2.5 square mm. The internal conductors of this cable are protected using semiconductive tapes, copper braid shielding which is further reinforced with gray colored PVC jacket. This cables offers hight conductivity, high flexibility and minimize the corona losses. The cable is diligently designed to withstand high voltage ranging upto 75 kVDC. A notch is provided on the side wall of the connectors which assures mistake-proof fit during installation. Black colored caps are provided with the connectors to protect the contacts from damages. For ease of identification this cable comes with color coded, pre-labeled information about the connecting ends.

Compatible Products

Optima 520

Optima 520

Equivalent Part :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
5128609-4
