AMX 4 Disc Assembly
46-286973G1
46-286973G1-H
X-Ray
Definium AMX700
GE Healthcare
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.


Product Overview

The AMX 4 Disc Assembly is used in X-ray systems and other demanding applications. The friction elements are squeezed inwards to a clamp, a rotating disc or wheel. The disc assembly is comprised of a caliper, disc, mechanical material comp, backing disc, washer, backing pad, and related hardware (bolts, clips, and springs). The caliper is a supporting part mounted on the spindle and fitted with one or more pistons that are hydraulically actuated by the fluid pressure. The disc is bored to be concentric with bore in calipers after assembly. After assembly, the disc will not slip at less than 600 in-lbs of torque. The disc will slip at an excess of 1270 in-lbs of torque. To prevent the pressure leakage between the piston and cylinder, the piston seal is used. It is made from a steel sheet which possesses reflectivity, impermeable, corrosion resistant and recyclability.

Compatible Products

Definium AMX700

Definium AMX700

Equivalent Part :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
46-286973G1-H

AMX 4 - DISC ASSEMBLY
